Balzer
Features
- Available in 6, 8, 10, or 13 foot lengths
- Either 540 or 1000 RPM
- 6″ x 5/16″ unload pipe with bi-direction load or agitate valve
- Two point mount hydraulic tilts into pit openings as small as 30″ x 48″
- 7″x7″x1/4″ Main Beam
- Main Drive line
- Heavy duty 200 Hp gear box, 1:1.35 ratio
3″ OD hollow drive line with upper and lower greasable yokes - Stainless impeller shaft
- Triple seal oil bath bearing assembly with 1-3/4″ stainless steel lower shaft.
- Oil Level glass
- 20″ diameter, 4″ depth, impeller with 6-1/2″ long, thick, curved Blades
- Replaceable triple cutters on impeller opening
- Large intake throat
- AR Steel impeller housing
- Stainless Steel Agitation gun
- Hydraulic controls-nozzle rotate, raise-lower, and agitate-load (Requires 3 hydraulic outlets)
- Optional hydraulic control valve (Requires hydraulic outlets)
- Hitch type: 2 point category II or III
Options
- Trailer Mounted
- 3 pt. Quick-Tach Hook-up
Hydraulic Controls Kit - Controls load agitate valve
- Controls agitation nozzle horizontally and vertically
- Requires 3 hydraulic outlets
- Hydraulic control valve
- Electric powered models
- Gear Box cooling system (only available on 1000 rpm pumps)
Pump Specifications
Models | 6″ | 8″ |
| Performance: (Gallons per minute) | 4000 | 5000 |
| Minimum hp requirements: | 110 hp | 140 hp |
| Unload Pipe: | 6″ x 5/16″ | 8″ x 5/16″ |
| Pump Impeller Size: | 20″ diameter x 4″ depth AR steel | 22″ diameter x 4″ depth AR steel |
